Sony KL-40WA1K [4/31] Overview
![Sony KL-40WA1K [4/31] Overview](/views2/1091289/page4/bg4.png)
4
Name
Main power switch
Standby indicator
Stereo A/B indicators
Lamp indicator
Programme
Volume buttons
Input select buttons
Headphones jack
Input jacks (S video/video/audio)
Symbol
u
u
A-m -B
PROGR+/–
. +/–
l
S
3, 3, 3
Overview
This section briefly describes the buttons and controls on the TV
set and on the Remote Commander. For more information, refer to
the pages given next to each description.
TV set-front
Refer to page
14
14, 31
17
29, 31
14
14
15
23
24
