Hitachi CJ18DSL [11/100] English

English

SPECIFICATIONS

Cordless Jig Saw

CAUTION

1. If liquid leaking from the battery gets into your eyes,

do not rub your eyes and wash them well with fresh

clean water such as tap water and contact a doctor

immediately.

If left untreated, the liquid may cause eye-problems.

2. If liquid leaks onto your skin or clothes, wash well

with clean water such as tap water immediately.

There is a possibility that this can cause skin irritation.

3. If you find rust, foul odor, overheating, discolor,

deformation, and/or other irregularities when using

the battery for the first time, do not use and return it

to your supplier or vendor.

Model CJ14DSL CJ18DSL

Voltage 14.4 V 18 V

Max. Cutting Depth Wood 135 mm Mild Steel 10 mm

No-Load Speed 0 – 2400 min

–1

Stroke 26 mm

Min. Cutting Radius 25 mm

Rechargeable battery

BSL1430: Li-ion 14.4 V BSL1830: Li-ion 18 V

(3.0 Ah, 8 cells) (3.0 Ah, 10 cells)

Weight 2.3 kg 2.4 kg

STANDARD ACCESSORIES

Standard accessories are subject to change without notice.

OPTIONAL ACCESSORIES ... Sold separately

(1) Various types of blades

Refer to Table 5 for use of the blades.

(2) Guide

(3) Sub base

(4) Dust collector

Optional accessories are subject to change without notice.

1 Blades (No. 41) ....................... 1

Refer to Table 5 for use of the blades.

2 Hexagon bar wrench ............. 1

CJ14DSL

3 Splinter guard ......................... 1

(2LSCK)

4 Chip cover ............................... 1

CJ18DSL

5 Charger ..................................... 1

(2LSCK)

6 Battery ...................................... 2

7 Plastic case .............................. 1

8 Battery cover ........................... 1

CJ14DSL (NN) Without charger, battery,

CJ18DSL (NN) plastic case and battery cover

APPLICATIONS

䡬 Cutting various lumber and pocket cutting

䡬 Cutting mild steel plate, aluminum plate, and copper

plate

䡬 Cutting synthetic resins, such as phenol resin and vinyl

chloride

䡬 Cutting thin and soft construction materials

䡬 Cutting stainless steel plate (with No. 97 blade)

BATTERY REMOVAL/INSTALLATION

1. Battery removal

Hold the handle tightly and push the battery latch to

remove the battery (See Fig. 2).

CAUTION

Never short-circuit the battery.

2. Battery installation

Insert the battery while observing its polarities (See

Fig. 2).

CHARGING

Before using the cordless jig saw, charge the battery as

follows.

1. Connect the charger’s power cord to a receptacle.

When the power cord is connected, the charger’s pilot

lamp will blink in red. (At 1-second intervals)

Charger

Model UC18YRSL

Charging voltage 14.4 V 18 V

Weight 0.6 kg

WARNING

If an electrically conductive foreign object enters the

terminals of the lithium ion battery, a short-circuit may

occur resulting in the risk of fire. Please observe the

following matters when storing the battery.

䡬 Do not place electrically conductive cuttings, nails,

steel wire, copper wire or other wire in the storage

case.

䡬 Either install the battery in the power tool or store

by securely pressing into the battery cover until the

ventilation holes are concealed to prevent short-

circuits (See Fig. 1).

01Eng_CJ14DSL_EE 3/19/08, 13:4510
