English

2.12 Onboard Headers and Connectors

System Panel Header

(9-pin PANEL1) (see p.6, No. 18)

Connect the power button, reset button and system status indicator on the chassis

to this header according to the pin assignments below. Note the positive and

negative pins before connecting the cables.

GND

R ESET#

P WRBTN#

P LED-

P LED+

GND

H DLED-

H DLED+

GND

PANEL1

Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over

these headers and connectors. Placing jumper caps over the headers and connectors

will cause permanent damage to the motherboard.

PWRBTN (Power Button):

Connect to the power button on the chassis front panel. You may congure the way

to turn o your system using the power button.

RESET (Reset Button):

Connect to the reset button on the chassis front panel. Press the reset button to

restart the computer if the computer freezes and fails to perform a normal restart.

PLED (System Power LED):

Connect to the power status indicator on the chassis front panel. e LED is on when

the system is operating. e LED keeps blinking when the system is in S1/S3 sleep

state. e LED is o when the system is in S4 sleep state or powered o (S5).

HDLED (Hard Drive Activity LED):

Connect to the hard drive activity LED on the chassis front panel. e LED is on

when the hard drive is reading or writing data.

e front panel design may dier by chassis. A front panel module mainly consists

of power button, reset button, power LED, hard drive activity LED, speaker and etc.

When connecting your chassis front panel module to this header, make sure the wire

assignments and the pin assignments are matched correctly.
