ASRock B650 LiveMixer [51/61] Smart switches
![ASRock B650 LiveMixer [51/61] Smart switches](/views2/1921114/page51/bg33.png)
English
47
B650 LiveMixer
2.13 Smart Switches
e motherboard has one smart switch: BIOS Flashback Button, allowing users to
ash the BIOS.
BIOS Flashback Button
(BIOS_FB1) (see p.8, No. 10)
BIOS Flashback Button allows users to ash the BIOS.
USB BIOS Flashback port
BIOS_FB1
