ASRock B650 LiveMixer [7/61] Rear panel i o
![ASRock B650 LiveMixer [7/61] Rear panel i o](/views2/1921114/page7/bg7.png)
English
3
B650 LiveMixer
Audio
•
7.1 CH HD Audio (Realtek ALC897 Audio Codec)
•
Nahimic Audio
LAN
•
2.5 Gigabit LAN 10/100/1000/2500 Mb/s
•
Dragon RTL8125BG
•
Supports Dragon 2.5G LAN Soware
- Smart Auto Adjust Bandwidth Control
- Visual User Friendly UI
- Visual Network Usage Statistics
- Optimized Default Setting for Game, Browser, and
Streaming Modes
- User Customized Priority Control
USB
•
1 x USB 3.2 Gen2x2 Type-C (Front)
•
1 x USB 3.2 Gen2 Type-C (Rear)
•
1 x USB 3.2 Gen2 Type-A (Rear)
•
8 x USB 3.2 Gen1 (4 Rear, 4 Front)
•
12 x USB 2.0 (8 Rear, 4 Front)
* All USB ports support ESD Protection
Rear Panel
I/O
•
2 x Antenna Mounting Points
•
1 x HDMI Port
•
1 x DisplayPort 1.4
•
1 x Optical SPDIF Out Port
•
1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (ReDriver)
•
1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (ReDriver)
•
4 x USB 3.2 Gen1 Ports (USB32_12 are Lightning Gaming
Ports. USB32_34 support Ultra USB Power.)
•
8 x USB 2.0 Ports
•
1 x RJ-45 LAN Port
•
1 x BIOS Flashback Button
•
1 x Line Out Jack (Gold Audio Jack)
•
1 x Microphone Input Jack (Gold Audio Jack)
Storage
CPU:
•
1 x Blazing M.2 Socket (M2_1, Key M), supports type
2260/2280 PCIe Gen5x4 (128 Gb/s) mode*
