KN1000A User Manual

156

3. Select the KN1000A in the Device List.

Note: 1. If the list is empty, or your device does not appear, click

Enumerate to refresh the Device List.

2. If there is more than one device in the list, use the MAC address

to pick the one you want. The KVM over IP switch’s MAC

address is located on its bottom panel.

4. Select the Protocol and Network adapter.

5. Select either Obtain an IP address automatically (DHCP), or Use the

following IP address. If you chose the latter, fill the IP Address, Subnet

Mask, and Default Gateway fields with the information appropriate to

your network.

6. Click Set IP.

7. After the IP address shows up in the Device List, click Exit. See IP

Installer, page 155 for more information.

Browser

1. Set your computer's IP address to 192.168.0.XXX

Where XXX represents any number or numbers except 60. (192.168.0.60 is

the default address of the KN1000A.)

2. Specify the switch's default IP address (192.168.0.60) in your browser, and

you will be able to connect.

3. Assign a fixed IP address for the KN1000A that is suitable for the network

segment that it resides on.

4. After you log out, reset your computer's IP address to its original value.

AP Windows Client

For computers running Windows, the KN1000A's IP address can be

determined with the Windows AP program (see The WinClient AP, page 136).

When you run the program it searches the network segment for KN1000A

devices, and displays the results in a dialog box similar to the one below:

You can now use this network address, or you can change it by clicking Login,

logging in, clicking Open GUI, and clicking the Network tab. See Network,

page 40, for details.
