![Aten KN1000A [21/196] Features benefits](/views2/1977356/page21/bg15.png)
Chapter 1. Introduction
5
Smart Card / CAC
Reader Support
To meet advanced security requirements, the KN1000A’s Virtual
Media function allows a Smart Card / CAC reader on a user’s local
system to be mapped to a remote server.
Built-in Single
Port Power
Switch
Allows remote power management of a server/installation
connected locally to the KN1000A, including turning servers On,
Off and Rebooting
Low Bandwidth
Optimization
Bandwidth optimization via grayscaling and video quality settings
allow maximum data throughput in low bandwidth situations. PPP
modem dialup support ensures reliable connectivity for out-of-
band, and low bandwidth situations.
Multi-Platform /
Multi
-
Protocol
Support
Windows and Java client software ensures that the KN1000A and
the equipment that connects to it can be accessed from most of the
operating systems in use today (Windows, Linux, Unix, Sun, Mac).
The KN1000A also supports a broad range of communication
protocols, such as TCP/IP, HTTP, HTTPS, UDP, DHCP, SSL, ARP,
DNS, ICMP, CHAP, PPP, 10Base-T and 100Base-T.
Manage Browser
Access Methods
Use either HTTP, HTTPS, or disable the browser.
Multi-Keyboard
Language
Support /
On-Screen
Keyboard
The KN1000A supports multiple keyboard language inputs –
including English, French, German, Italian, Spanish, Japanese,
Korean, and Traditional Chinese. There is no need to have a
separate keyboard for each language – you can input key data in
any of these languages with the KN1000A's convenient on-screen
keyboard.
Multi-Users /
Multi-Logins
The KN1000A supports up to 64 user accounts, and allows up to
32 concurrent user logins for single-bus access.
Message Board To alleviate the possibility of access conflicts that may result from
multiple user logins, and facilitate communication among the
logged-in users, a message board – similar to an Internet chat
program – allows users to communicate with each other, and
provides mechanisms for a user to take exclusive control of the
KVM functions.
Features Benefits
