KN1000A User Manual
6
Advanced
Security
Advanced security features include password protection –
whereby a valid username and password must be given before
the client software will run – and advanced encryption
technologies, such as secure 128-bit SSL.
Supports SSL 128-bit data encryption and RSA 1024-bit
certificates for secure users logging in from a browser.
Flexible encryption design allows users to choose any
combination of 56-bit DES, 168-bit 3DES 256-bit AES, 128-bit
RC4, or Random for independent KB/Mouse, video, and virtual
media data encryption.
IP/MAC Filter for enhanced security protection
Supports password protection
Private CA
External
Authentication
Support
In addition to its own security protection, the KN1000A allows you
to set up login authentication and authorization management from
a external sources such as RADIUS, LDAP, LDAPS, and MS Active
Directory.
Event Logging The KN1000A can record all the events that take place on it and
write them to a searchable database. Administrators and selected
users can search for events containing specific words or strings
and retrieve them according to date and order of significance.
Console
Management
Serial console management – serial terminal access. Access the
KN1000A via a built-in serial viewer, or via third-party software
(such as PuTTY) for Telnet and SSH sessions.
Out of Band Support – via dial up modem support. Access the
KN1000A through its RS-232 port using a dial-up connection.
Upgradeable
Firmware over
the Internet
No need to add yet another cable to your installation – stay current
with the latest functionality improvements and updates, all over the
Internet.
Mouse DynaSync No need to resync your mouse – Mouse DynaSync provides
automatic locked-in synching of the remote and local mouse
pointers – eliminating the need to constantly resync the two
movements. Your local console mouse movement becomes the
remote unit’s mouse movement.
Auto-Ping Pings a device to determine its status; if the ping test fails after a
set amount of time it automatically takes an action assigned.
Supports Multiple
Interfaces
Supports PS/2, USB, Sun Legacy (13W3)* and serial (RS-232)
connectivity
*Requires CV130A converter purchase
Features Benefits
