Chapter 1

Introduction

Overview

The CE820 / CE920 HDBaseT 2.0 KVM Extender can extend HDMI (CE820

only), DisplayPort (CE920 only), serial, Ethernet (for device supporting the

Ethernet port only), and USB 2.0 signals up to 100 meters using a single Cat

5e/6/6a or ATEN 2L-2910 cable and HDBaseT technology. The HDBaseT 2.0

KVM Extender is equipped with USB connectors which allow you to extend

signal transmission of any USB device. The USB functionality provides

support for peripheral sharing, touch panel control and file transfers. The

CE820 / CE920 ensures superior video quality with 4096 x 2160 resolutions so

that you get the most out of your HDMI / DisplayPort-enabled displays.

The CE820 / CE920 supports the HDBaseT™ 2.0 technology with which you

can extend the KVM installation up to 150 meters @ 1080p and preserve high-

quality video by enhancing bit error detection and correction to resist signal

interference.

The CE820 / CE920 allows access to a computer system from a remote console

(USB keyboard, monitor, and mouse). It is perfect for use in any type of

installation where you need to place the console where it is conveniently

accessible, but you want the system equipment to reside in a safe location –

away from the dust and dirt of the factory floor, or the harsh environmental

influence of a construction site, for example. This allows users to deploy

system equipment over large distances.

The CE820 / CE920 is useful for control and security purposes, where you can

have the system in a secure area with the console in the most convenient

location for user access. This is ideal for managing highly confidential data

systems.

The CE820 / CE920 is ideal for transportation centers, medical facilities, and

shopping malls, industrial kiosks and for syncing files and folders between

computers. Setup is as easy as can be – simply connect the computer; run the

Cat 5e/6/6a or ATEN 2L-2910 cable up to 100 meters to the remote unit of the

CE820/CE920 and then plug the remote console into the remote unit of CE820

/ CE920.
