CE820 / CE920 User Manual
2
Features
Supports HDBaseT™ 2.0 technology
Extends video (HDMI for CE820 and DisplayPort for CE920), audio,
USB, RS-232, and Ethernet signals (for device supporting the Ethernet
port only) via a single Cat6 / 6a cable or an ATEN 2L-2910 Cat 6 cable
Enhanced bit error detection and correction to resist signal interference
during high-quality video transmissions
Status detection and LED indication for HDBaseT™ signal
transmission on remote unit
EDID Buffer for smooth power-up and the highest quality display
HDMI: 3D, Deep Color, 1080P, 4K (for CE820)
HDCP 2.2 Compatible (for CE820)
HDCP Compatible (for CE920)
Long distance with superior video quality
HDBaseT™ Standard mode up to 4K @ 100 m (Cat 6/6a or ATEN 2L-
2910 Cat 6 cable)
HDBaseT™ Long-reach mode up to 1080P @ 150 m
Long Reach mode switch – switches between HDBaseT™ Standard and
Long Reach modes in a snap
Supports individual 2-channel stereo audio for high-quality audio
applications
USB 2.0 full speed ports – ensures fast transmission speeds for peripherals
Supports PC wakeup function via single pushbutton through RS-232
channel*
Easy Installation Rack Mounting Kit
Built-in 8KV / 15KV ESD protection (Contact voltage 8KV; Air voltage
15KV)
Firmware upgradeable
Note: * The computer has to support Wake Up Ring for this function to
work.
