19
Chapter 3
Operation
Overview
This chapter provides information on LED indicators and how to use HDBaseT
Long Reach Mode.
LED Display
The local and remote units of CE820/CE920 have front panel LEDs to indicate
their operating status, as shown in the table below:
Long Reach Mode
The Long Reach Mode switch on the rear of the CE820/CE920 provides
long-reach connectivity up to 150 m, and resolutions up to 1080p. To use this
feature, put the Long Reach Mode switch to ON on either the remote or the
local unit of the CE820/CE920.
LED Indication Description
Power Lights green The system is receiving power.
Link Lights orange The connection between the local and remote CE820/
CE920 is stable.
Off The system detects a connection issue between the
local and remote CE820/CE920.
Flashes orange The HDBaseT signal transmission is unstable.
Video Out Lights orange The video display normal and secured with HDCP.
Flashes orange The video display is normal but not secured with
HDCP.
Off There is no video activity.
Note: The Video Out LED is only available on the remote unit of CE820/CE920.
LONG
REACH
F/W
UPGRADE
ON
OFF
