Aten CL3108 [14/80] Features
![Aten CL3108 [14/80] Features](/views2/1977494/page14/bge.png)
CL3108 / CL3116 User Manual
2
Features
Space Usage Optimization
Exclusive LED illumination — designed by ATEN to illuminate the
keyboard and touchpad for operation under low-light conditions
Integrated LCD KVM console with an 18.5'' LED-backlit widescreen
LCD monitor in a single rail housing with top and bottom clearance for
smooth operation in a 1U system rack
Short-depth design allowing you to work with varying rack-mounting
equipment within narrow spaces
Console lock — enables the console drawer to remain securely locked
away when not in use
Reliability and Operational Versatility
Superior video quality — up to 1366 x 768, DDC2B
Cascade up to 2 levels — CL3108 / CL3116 can control up to 128 / 256
computers from a single console (With compatible KVM Switches:
CS1308, CS1316)
Dual Interface — supports computers with PS/2 or USB keyboard and
mouse interface
Auto PS/2 and USB interface detection
Keyboard and mouse emulation (PS/2 and USB) for smooth switching and
simultaneously booting multiple computers even when the console focus
is elsewhere
Computer selection via pushbuttons, hotkeys, and multilingual on-screen
display (OSD)
Broadcast mode — allows you to send commands from the console to all
computers to perform operations simultaneously
Two-level password security — only authorized users can view and
control computers
Auto Scan mode — enables automated monitoring of user-selected
computers
Keyboard Language supports: English (US), English (UK), German
(GER.), German (SWISS), French, Hungarian, Italian, Japanese, Korean,
Russian, Spanish, Swedish, and Traditional Chinese
Additional hot-pluggable USB mouse port on front panel that supports
HID device for keyboard and mouse
