Chapter 1. Introduction
3
Installation Flexibility
Standard rack mount kit included
Optional rack mount kits available including easy installation options
No software required
Firmware upgradable
Supports hot-plugging
Requirements
Computers
The following hardware components are required for each computer:
A VGA, SVGA, or multisync video graphics card with an HDB-15 port.
PS/2 mouse and keyboard ports (6-pin mini-DIN), or at least one USB
port.
Cables
Substandard cables might damage or affect the overall performance of the
connected devices. For optimum signal integrity and a simplified layout, please
use the high-quality custom cable sets described below.
Operating Systems
Supported operating systems include Windows, Mac, Linux, and Sun.
Function Length Part Number
KVM switch to computer PS/2 1.2 m
1.8 m
3.0 m
6.0 m
1.8 m
2L-5201P
2L-5202P
2L-5203P
2L-5206P
2L-5702P
USB 1.2 m
1.8 m
3.0 m
5.0 m
2L-5201U
2L-5202U
2L-5203U
2L-5205U
PS/2-USB 1.2 m
1.8 m
3.0 m
2L-5301UP
2L-5302UP
2L-5303UP
