PE6108AV / PE6208AV / PE8208AV User Manual
96
PE8208AVB / PE8208AVG
Function PE8208AVB PE8208AVG
Power Outlets Direct 8
Connectors Power Inlet 1 x IEC 60320 C20
Power Outlets 8 x IEC 60320 C13
Sensor 2 x RJ-11
LAN 1 x RJ-45 (F)
RS-232 1 x DB-9 (M)
LEDs Current / IP 2-digit 7-segment (Yellow)
Outlet Power 8 (Orange)
Local 8 (Green)
Current 1 (Red)
Link 1 (Green)
Sensor 2 (Green)
Power 1 (Blue)
LAN 10/100M 1 (Orange / Green)
Switches Reset 2 x Semi-recessed Pushbutton
Power 1 x Rocker
Remote/Outlet
ON/Off
8 x Pushbutton
Current / IP 1 x Pushbutton
I/P Rating 100 – 240 V~; 50 - 60 Hz;
20 A (Max); 16 A (UL de-
rated)
100 – 240 V~; 50 - 60 Hz;
16 A
Load Capacity 4160 V A (Max) 3680 V A (Max)
O/P Rating Per Port 100 – 240 V~; 50 - 60 Hz;
15 A (Max); 12 A (UL de-
rated)
100 – 240 V~; 50 - 60 Hz;
10 A (Max)
Per Bank 100 – 240 V~; 50 - 60 Hz;
20 A (Max); 16 A (UL de-
rated)
100 – 240 V~; 50 - 60 Hz;
16 A (Max)
Total 100 – 240 V~; 50 - 60 Hz;
20 A (Max); 16 A (UL de-
rated)
100 – 240 V~; 50 - 60 Hz;
16 A (Max)
Environment Operating Temperature
0 – 50
o
C
Storage Temperature
-20 – 60
o
C
Humidity 0–80% RH Non-condensing
Physical
Properties
Housing Metal
Weight TBD TBD
Dimensions (L x W x H) 43.24 x 4.40 x 25.84 cm
