![Aten PE6208AV [14/110] Requirements](/views2/1978012/page14/bge.png)
PE6108AV / PE6208AV / PE8208AV User Manual
4
Requirements
Browsers accessing the eco PDU unit must support TLS 1.0.
For cold booting of attached computers, the computer's BIOS must
support Wake on LAN or System after AC Back.
For Safe Shutdown:
The computer must be running Windows (Windows 2000 or higher) or
Linux.
The Safe Shutdown program — PMonitor — must be installed and
running on the computer (available by download from our website).
Note:Safe shutdown program PMonitor can be the
Support and Download section of the product web page, as shown
below
