1
Chapter 1
Introduction
Overview
ATEN NRGence PE6108AV / PE6208AV / PE8208AV eco PDUs are
intelligent PDUs that contain 8 AC outlets with a detachable front panel for
convenient rack mounting and are available in various IEC or NEMA socket
configurations.
They provide secure, centralized, intelligent, power management (power on,
off, cycle) for data center IT equipment (servers, storage systems, KVM
switches, network devices, serial data devices, etc.), as well as the ability to
monitor the center's health environment via sensors*. The basic characteristics
of each model are shown in the table on page 3.
NRGence eco PDUs offer remote power control combined with real-time
power measurement - allowing you to control and monitor the power status of
devices attached to the PDUs, either at the PDU and outlet level (PE8208AV)
or Bank level (PE6208AV), from practically any location via a TCP/IP
connection.
The power status of each outlet can be set individually, allowing users to switch
each device On/Off. The eco PDU also offers comprehensive power analysis
reports when used with the eco DC (eco PDU manager web GUI) which can
separate departments and locations, providing precise measurements of
current, voltage, power and watt-hour in a real-time display.
Installation and operation is fast and easy: plugging cables into their
appropriate ports and user-friendly browser-based configuration and
management is all that is entailed. Since the eco PDU firmware is upgradeable
over the Net, you can stay current with the latest functionality improvements
simply by downloading updates from our website as they become available.
NRGence eco PDU supports any 3rd party v3 SNMP manager software and
NRGence eco DC (eco PDU manager web GUI). NRGence eco DC provides
you with an easy method for managing multiple devices, offering an intuitive
and user-friendly Graphical User Interface that allows you to configure a PDU
device and monitor power status of the equipment connected to it.
This series of ATEN eco PDUs have threshold alerts that can sound an alarm
and send SNMP trap or e-mail alerts when a threshold is exceeded. This feature
