Skil 7470 NA [7/100] Application advice

Skil 7470 NA [7/100] Application advice
7
- release the trigger
- unlock the switch by pulling again trigger F 2 and then
releasing it
Speed control 5
For optimal sanding results on dierent materials
- with wheel H 2 you can adjust the sanding speed
steplessly from minimum to maximum
- always adjust speed to grit size used
- before starting a job, nd the optimal speed and grit by
testing out on spare material
Holding and guiding the tool 6
! while working, always hold the tool at the
grey-coloured grip area(s)
- guide the tool parallel to the working surface and move
it in circles or in a cross pattern
! do not apply too much pressure on the tool; let
the sanding surface do the work for you
- do not tilt the tool in order to avoid unwanted sanding
marks
- keep ventilation slots J 2 uncovered
Sanding
- the amount of material removed is determined by the
speed of the sanding disc
- the speed of the sanding disc diminishes relative to
the pressure applied to the tool
APPLICATION ADVICE
For determining the optimal grit (and speed), table 7 can
be used as reference
! always test out first on a piece of scrap material
MAINTENANCE / SERVICE
Always keep tool and cord clean (especially ventilation
slots J 2)
- remove adhering sanding dust with a brush
! disconnect the plug before cleaning
If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool undismantled together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skilmasters.com)
ENVIRONMENT
Do not dispose of electric tools, accessories and
packaging together with household waste material
(only for EU countries)
- in observance of European Directive 2002/96/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol 8 will remind you of this when the need for
disposing occurs
DECLARATION OF CONFORMITY
We declare under our sole responsibility that this product
is in conformity with the following standards or
standardized documents: EN 60745, EN 61000,
EN 55014, in accordance with the provisions of the
directives 2004/108/EC, 2006/42/EC
Technical file at: SKIL Europe BV (PT-SEU/PJE),
4825 BD Breda, NL
ÊÆÇιÆ¼½ÊÄÇÇÌ
Á»½ʽËÁ¼½ÆÌ
ȽʹÌÁÇÆËŵÆ¿Áƽ½ÊÁÆ¿
ÍÊÇȽƓˁ˅ʿ˂ʽ¼¹Ɠ
¹ÆÊÇÅŽĽÆ
ÈÈÊÇιÄ¹Æ¹¿½Ê
12.07.2011
NOISE/VIBRATION
Measured in accordance with EN 60745 the sound
pressure level of this tool is 69 dB(A) and the sound
power level 80 dB(A) (standard deviation: 3 dB), and the
vibration 5.3 m/s² (hand-arm method; uncertainty K =
1.5 m/s²)
The vibration emission level has been measured in
accordance with a standardised test given in EN 60745; it
may be used to compare one tool with another and as a
preliminary assessment of exposure to vibration when
using the tool for the applications mentioned
- using the tool for dierent applications, or with dierent
or poorly maintainted accessories, may signicantly
increase the exposure level
- the times when the tool is switched o or when it is
running but not actually doing the job, may signicantly
reduce the exposure level
! protect yourself against the effects of vibration
by maintaining the tool and its accessories,
keeping your hands warm, and organizing your
work patterns
Ponceuse excentrique 7470
INTRODUCTION
Cet outil est conçu pour le ponçage à sec du bois,
plastique, métal et mastic et des surfaces peintes
Lisez et conservez ce manuel d’instruction 3
SPECIFICATIONS TECHNIQUES 1
ELEMENTS DE L’OUTIL 2
A Support plateau
B Vis du support plateau
C Disque de ponçage
D Réservoir à poussière
E Bouton de retrait du réservoir à poussière
F Interrupteur marche/arrêt
G Bouton de verrouillage de l’interrupteur marche/arrêt
