Lenovo ThinkPad X230t [100/182] Replacing the palm rest

11.Turnthecomputeroverandreinstallthescrews.

12.Reinstallthebattery.See“Replacingthebattery”onpage72.

13.Turnthecomputeroveragain.Connecttheacpoweradapterandallcables.

Replacingthepalmrest

Beforeyoustart,printtheseinstructions.

DANGER

Electriccurrentfrompower,telephone,andcommunicationcablesishazardous.Toavoidshock

hazard,disconnectthecablesbeforeopeningthecoverofthisslot.

Toremovethepalmrest,dothefollowing:

1.Turnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.Waitfor

threetoveminutes,tilltheinsideofthecomputercools.

2.Closethecomputerdisplay,andturnthecomputerover.

3.Removethebattery.See“Replacingthebattery”onpage72.

4.Removethekeyboard.See“Replacingthekeyboard”onpage81.

84UserGuide
