Lenovo ThinkPad X230t [27/182] Features

TheWindowsCerticateofAuthenticitylabelofyourcomputerisshownasbelow:

Features

Processor

•Toviewtheprocessorinformationofyourcomputer,opentheStartmenuandright-clickComputer,

thenclickProperties.

Memory

•Doubledatarate3synchronousdynamicrandomaccessmemory(DDR3SDRAM)

Storagedevice

•2.5-inch(7mmheight)harddiskdrive

•2.5-inch(7mmheight)solid-statedrive

Systemperformance

•mSATAsolid-statedrive

Display

ThecolordisplayusestheThinFilmTransistor(TFT)technology.

•Size:12.5inches(317.5mm)

•Resolution:

–LCD:1366-by-768

–Externalmonitor:Upto2560-by-1600

•LEDbacklight

•Brightnesscontrol

•Integratedcamera

•Built-inmicrophones

Chapter1.Productoverview11
