Lenovo ThinkPad X230t [21/182] Left side view
![Lenovo ThinkPad X230t [21/182] Left side view](/views2/1984010/page21/bg15.png)
However,ifyouwanttochargethesedeviceswhenyourcomputerispoweredoff,youneedtoconnectthe
computertoanacpowersupplyandenabletheAlwaysOnUSBconnectorthroughthePowerManager
program.FordetailsabouthowtoenabletheAlwaysOnUSBconnector,refertothehelpinformation
systemprovidedinthePowerManagerprogram.
7Mediacardreaderslot
Yourcomputerhasamediacardreaderslot.Forinformationaboutthesupportedcards,see“Usingan
ExpressCard,aashmediacard,orasmartcard”onpage46.
Left-sideview
Figure3.ThinkPadX230TabletandX230iTabletleft-sideview
1ExpressCardslot
2Wirelessradioswitch
3USB3.0connectors
4DisplayPortconnector
5Videographicsarray(VGA)connector6Fanlouvers(left)
1ExpressCardslot
YourcomputerhasanExpressCardslotfora54mm-wideExpressCardorasmartcard.Formore
information,see“UsinganExpressCard,aashmediacard,orasmartcard”onpage46
.
2Wirelessradioswitch
Usethisswitchtoquicklyturnonorturnoffallwirelessconnections.
3USB3.0connectors
TheUniversalSerialBus(USB)3.0connectorsareusedforconnectingdevicescompatiblewithaUSB
interface,suchasaUSBprinteroradigitalcamera.
Note:WhenyouattachaUSBcabletotheconnector,makesurethattheUSBmarkisfacingupward.
Otherwisetheconnectormightbedamaged.
4DisplayPortconnector
UsetheDisplayPortconnectortoconnectyourcomputertoacompatibleprojector,externalmonitor,or
high-denitiontelevision.
Chapter1.Productoverview5
