Usingthetabletbuttons
Onthedisplaybezelnearthescreenisarowofbuttonswithwhichyoucancontrolyourcomputerintablet
mode,withouttheuseofthekeyboard.
1Screenrotationbutton:Pressittorotatethescreenclockwise.
2SecureAttentionSequencebutton:ThisbuttonfunctionsthesameastheCtrl+Alt+Delkeycombination.
3Powerbutton:Pressittoturnthecomputeronoroff.
UsingtheTabletShortcutMenu
TabletShortcutMenuisasoftwaretoolbarthatisoptimizedforusewhenyourcomputerisintabletmode.
FromthismenuyoucanadjustcertainsystemsettingsandstarttheThinkPadutilityprograms,suchas
AccessConnectionsandPresentationDirector.Themenualsoprovidesfunctionsthatareusefulintablet
mode,suchaschangingthescreenorientationautomaticallyfordifferentpositionsofthecomputer,
disablingtheBeamFormingfeatureautomaticallyintabletmode,orresumingthesystemfromstandby
whentheTabletDigitizerPenisremovedfromitsslot.
TostarttheTabletShortcutMenu,clickStart➙AllPrograms➙LenovoThinkVantageT ools➙T ablet
Utility.
Fordetails,refertotheHelpintheTabletShortcutMenu.
Specialkeysandbuttons
Yourcomputerhasseveralspecialkeysandbuttonstohelpyouworkmoreeasilyandeffectively.
26UserGuide
