Lenovo ThinkPad X230t [106/182] Replacing the wireless wan card
![Lenovo ThinkPad X230t [106/182] Replacing the wireless wan card](/views2/1984010/page106/bg6a.png)
13.Reinstallthekeyboard.See“Replacingthekeyboard”onpage81.
14.Reinstallthebattery.See“Replacingthebattery”onpage72.
15.Turnthecomputeroveragain.Connecttheacpoweradapterandallcables.
ReplacingthewirelessWANcard
Beforeyoustart,printtheseinstructions.
DANGER
Electriccurrentfrompower,telephone,andcommunicationcablesishazardous.Toavoidshock
hazard,disconnectthecablesbeforeopeningthecoverofthisslot.
Attention:BeforeyoustartinstallingawirelessWANcard,touchametaltableoragroundedmetalobject.
Thisactionreducesanystaticelectricityfromyourbody.Thestaticelectricitycoulddamagethecard.
ToreplacethewirelessWANcard,doingthefollowing:
1.Turnoffthecomputer,thendisconnecttheacpoweradapterandallcablesfromthecomputer.Waitfor
threetoveminutes,tilltheinsideofthecomputercools.
2.Closethecomputerdisplay,andturnthecomputerover.
3.Removethebattery.See“Replacingthebattery”onpage72.
4.Removethekeyboard.See“Replacingthekeyboard”onpage81.
5.Removethepalmrest.See“Replacingthepalmrest”onpage84.
6.Ifatoolforremovingconnectorsisincludedinthepackagewiththenewcard,useittodisconnectthe
cablesfromthecard.Ifnosuchtoolisincluded,disconnectthecablesbypickinguptheconnectors
withyourngersandgentlyunpluggingthem.
Note:Dependingonthesystemcongurationofyourcomputer,thecardmighthaveonlyoneconnector.
90UserGuide
