BlacklineX USERGUIDE
BlacklineXUserGuideV1.0 37
…………
UsetheEdit2Control[8]tochangethe delayby:
±1.000msperclick,or
±0.340mperclick,or
±1.115feetperclick
UsetheEdit3Control[9]tomakefineadjustments.
TheEdit3Controlchangesthedelayby:
±0.0208msperclick,or
±0.007mperclick,or
±0.023feetperclick
Turnin
gtheseControlsclockwiseincreasesthedelaytime,whileturningthemanticlockwisedecreasesthedelaytime.
Theminimumandmaximumdelayrangesfrom:
0.0000ms–600.9984ms
0.000m–204.339m
0.000feet–670.233feet
PresstheESCbutton[11]todisengageEdit
ing.
EQBypass
EQBypassflattensthe5‐BandEQontheinputsoyoumayhearexactlyhowitisaffectingthesystem.BytogglingtheEQBypass
onandoff,youmayquicklycompare thesoundwithandwithoutEQ.
TurntheEdit2[8]orEdit3[9]ControltoscrollbetweenBypass = Off[default]andBypass = On.
PresstheESCbutton[11]toacceptthenewEQBypassmodeandexittheEQBypasseditingmode.
5‐BandEQ
EditinginputEQontheDX0.5isusefulforadjustingtheresponseoftheentirePA,particularlywhencorrectinganomaliescaused
by venue acoustics. It is standard practice to use the input EQ for this function leaving the output EQ for any cabinet EQ
recommendedbythesystemmanufacturer.
PresstheEnterbutton[10]toenterandedittheEQbands.Anarrow–>willappearnexttoEQindicatingthatitisreadytobe
edited.
UsetheNav/Edit1[7]Controltochangethefrequencyby±1/24octaveperclick.Turningthiscontrolclockwiseincreasesthe
frequency,whileturningitanti‐clockw
isedecreasesthefrequency.Thefrequencyrangesfrom20.0Hzto20.0kHz.
UsetheEdit2[8]ControltochangetheQfactor(bandwidth)by±0.05perclick.TurningthisControlclockwiseincreasestheQ
factor,whileturningitanticlockwisedecreasestheQ.TheEQband maybeconfiguredashighorlowshelfbyturningitallthe
wayanti‐clock
wise.
ThesearetheEQchoicesfromthefurthestanticlockwiseoptiontothefurthestclockwiseoption:
–12HighShelving
–6HighShelving
–12LowShelving
–6LowShelving
0.05–3.00[Parametric]
TochangetheEQbetweenshelvingandparam
etric,thegainmustfirstbesetto0.0dB.
UsetheEdit3[9]Controltochangethegainby±0.5dBperclick.Turningthiscontrolclockwiseincreasesthegain,whileturning
itanti‐clockwisedecreasesthegain.Thegainrangesfrom–15.0dB to+15.0dB
.
