BlacklineX USERGUIDE
BlacklineXUserGuideV1.0 56
…………
X115
TYPE
Compact, direct radiating subwoofer
FREQUENCY RESPONSE (5)
45Hz-150Hz ± 3dB, -10dB @ 40Hz
DRIVER 15” (380mm)/3” (75mm) voice coil, long excursion, ferrite magnet
RATED POWER (2)
500W AES, 2000W peak
RECOMMENDED AMPLIFIER
MA3.0, MA5.0Q
SENSITIVITY (8)
102dB
MAXIMUM SPL (9)
129dB continuous, 135dB peak (half space)
NOMINAL IMPEDANCE
8 ohms
DISPERSION (-6dB)
Omnidirectional
CROSSOVER
80-120Hz active
ENCLOSURE
Birch/poplar ply
FINISH Black textured paint
PROTECTIVE GRILLE
Black perforated steel
CONNECTORS 3 x NL4 type
PIN CONNECTIONS (INPUT
1+/1-
PIN CONNECTIONS (LINK)
A: 1+/- to 1+/-, B: 2+/- to 1+/-
FITTINGS
16 x M10 inserts, pole-mount socket, 2 x bar handles, provision for castors
DIMENSIONS
(W) 465mm x (H) 590mm x (D) 565mm
(W) 18.3ins x (H) 23.2ins x (D) 22.2ins
WEIGHT
27kg (59.5lbs)
X118
TYPE
Compact, direct radiating subwoofer
FREQUENCY RESPONSE (5)
42Hz-150Hz ± 3dB, -10dB @ 38Hz
DRIVER 18” (460mm)/3” (75mm) voice coil, long excursion, ferrite magnet
RATED POWER (2)
500W AES, 2000W peak
RECOMMENDED AMPLIFIER
MA3.0, MA5.0Q
SENSITIVITY (8)
104dB
MAXIMUM SPL (9)
131dB continuous, 137dB peak (half space)
NOMINAL IMPEDANCE
8 ohms
DISPERSION (-6dB)
Omnidirectional
CROSSOVER
80-120Hz active
ENCLOSURE
Birch/poplar ply
FINISH Black textured paint
PROTECTIVE GRILLE
Black perforated steel
CONNECTORS
3 x NL4 type
PIN CONNECTIONS (INPUT
1+/1-
PIN CONNECTIONS (LINK)
A: 1+/- to 1+/-, B: 2+/- to 1+/-
FITTINGS
16 x M10 inserts, pole-mount socket, 2 x bar handles, provision for castors
DIMENSIONS
(W) 530mm x (H) 669mm x (D) 640mm
(W) 20.9ins x (H) 26.3ins x (D) 25.2ins
WEIGHT
33kg (72.7lbs)
