BlacklineX USERGUIDE
BlacklineXUserGuideV1.0 42
…………
GrilleRemovalandhornRotation
TheBlacklineXFullrangecabinetsmaybeusedin"landscape"orhorizontalorientation,mostobviouslywhenusedasamonitor
wedgebutalsowhenflowninfixedinstallations. For the speaker to performcorrectly it is necessarytorotatethehornflare
through 90° to preserve the horizontal and verticaldispersion. The speakers are designed to make this as straightf
orward as
possiblewithspring‐loadedgrilleswhichareeasilyremovedandhornsscrewedinplacewithPozidrivescrews.Itisalsopossible
torotatetheMartinAudiobadgeonthegrille.
GrilleRemoval
GrillesonBlacklineXcabinetsaredesignedtobeeasytoremovetofacilitatedriverrotation.Noscrewsareusedtoholdthemin
place;theyare manufacturedwithanaturalspringwhichholdsthemin place inslotsineachsideof the cabinets.Thegrilles
havetwoorthreegapsinthesi
desintowhichanappropriately‐sizedflat‐bladedscrewdrivercanbeinsertedtoassistinremoval.
Insertthescrewdriverbladeintooneofthegaps‐eitheratthetoporbottomofthecabinet.
