BlacklineX USERGUIDE
BlacklineXUserGuideV1.0 41
…………
Eachoutputhasapowerfullimiterthatmaybeusedtoprotectloudspeakersfromdamageduetoexcessiveoutputlevelsfrom
themixer. Limiter parameters are published for all Martin Audio systems on our website and whilst we accept that personal
preferencemaymeanthatotherparametersmaybechangedfromourpublishedfigu
res‐EQchangedforpersonalpreference
for example‐ we would strongly recommend that the recommended limiter parameters arealwaysused to maintain reliable
operationformanyyears.
ThreeLimitercontrolsmaybeedited:
Attack
Release
Threshold
UsetheNav/Edit1Control[7]tochangetheattacktime.TurningthisCont
rolclockwiseincreasestheattacktime,whileturning
itanti‐clockwisedecreasestheattacktime.Theattacktimerangesfrom5msto200ms.
Theattacktimeincrementdependsonwhereitiscurrentlyset:
5ms–20ms:±1msperclick
20ms–30ms:±5msperclick
30ms–100ms
:±10msperclick
100ms–200ms:±20msperclick
UsetheEdit2Control[8]tochangethereleasetimeby±0.1sperclick.Turningthiscontrolclockwiseincreasesthereleasetime,
whileturningitanti‐clockwisedecreasesthere
leasetime.Thereleasetimerangesfrom0.1sto3.0s.
UsetheEdit3Control[9]tochangethethresholdby±0.2dBuperclick.TurningthisControlclockwiseincreasesthethreshold,
whileturningitanticlockwisedecreasesthethreshold.Thethresholdrangesfrom–10.0dB
uto+20.0dBu.Asettingof+20.0dBu
isoff.
PresstheESCbutton[11]toexitlimitereditingmode.
VUMeter
Youmaychoos e betweenviewingthesignallevelorthelimiter’sgainreductionforeachoutput.Thesewillbedisplayedonthe
7‐segmentLEDmeters[16].
Turnthe Edit2[8]orEdit3[9]ControltoscrollbetweenVU-Meter = Level[default]andVU-Meter = Limiter
Act.Ifthelatterisselected,theClipLEDontheselectedoutput(s)willilluminatetoindicate0dBofgainreduction.Whenthe
signallevelexceedsthelimiterthreshold,thetopLimitLEDwillilluminatetoindicategainreductionisoccurring.AdditionalLEDs
willilluminateforevery3dBofgainreduction.
PresstheESCbutton[11]toaccepttheupdateandex
itVUMetereditmode.
LinkingInputsorOutputs
Itispossibletolinkmultipleinputsoroutputsandeditspecificparameterssimultaneously.Thisisusefulifyouwanttosetthe
gainonbothinputsto+1.0dB,forexample.Oryoucouldintroducea3dB cutat250HzonEQband3onoutputchannels1‐4.
Thissavesvalu
abletimeratherthanhavingtomakethesamechangeoneachinputoroutputandofcourseismoreaccurate.
Thechangesareabsolute,notrelative,soifyouwantdifferentvaluesforthesameparameteracrossotherinputsoroutputs,
youneedtomakethesechangesoneachinpu
toroutput.Tolink,simplypressandholdanyadditionalinputoroutputMute/
Editbuttons.Anychangedparameterswillaffectalllinkedinputsoroutputs.
ControlApplication
The DX0.5 can be controlled from a PC running the DX0.5 Application which is available asa free download from the Martin
Audio website. The application uses the USB connection to connect and enables a much easier way of editing the system
configurationcomparedtousingthefrontpanelmenus.TheDX0.5isNOTs
hippedpre‐loadedwithBlacklineXparametersbut
theyareavailableasaprojectfiletobeuploadedtotheDX0.5internalpresetlibraryusingthecontrolapplication.Forfulldetails
pleasedownloadtheDX0.5UserGuideontheDX0.5ProductPageontheMartinAudiowebsite.
