Accu Roller 250™ System Menu Accu Roller 250™ System Menu
American DJ® - www.americandj.com - Accu Roller 250™ Instruction Manual Page 20American DJ® - www.americandj.com - Accu Roller 250™ Instruction Manual Page 19
select “ON” to reset the color motor. Press MODE/ENTER to
confirm.
5. Press EXIT/DN to return to the main menu.
GOBO - When you activate this reset function, the fixture
will only reset the gobo wheel motor.
1. Access the main menu.
2. Tap the UP button until “RESE” is displayed, press MODE/
ENTER.
3. Tap the UP button until “GOBO” is displayed, press MODE/
ENTER to confirm.
4. The display will show “ON/OFF”. Press the UP button to
select “ON” to reset the gobo motor. Press MODE/ENTER to
confirm.
5. Press EXIT/DN to return to the main menu.
SHTR - When you activate this reset function, the fixture
will only reset the shutter/dimmer motor.
1. Access the main menu.
2. Tap the UP button until “RESE” is displayed, press MODE/
ENTER.
3. Tap the UP button until “SHTR” is displayed, press MODE/
ENTER to confirm.
4. The display will show “ON/OFF”. Press the UP button to
select “ON” to restart the shutter/dimmer motor. Press MODE/
ENTER to confirm.
5. Press EXIT/DN to return to the main menu.
TIME MAIN MENU -
LIFE - With this function you can display the total running
time of the unit.
1. Access the main menu.
2. Tap the UP button until “TIME” is displayed, press MODE/
ENTER.
3. Tap the UP button until “LIFE” is displayed, press MODE/
ENTER.
4. Press EXIT to return to the main menu.
LAMP - With this function you can display the running time
of the lamp.
1. Access the main menu.
2. Tap the UP button until “TIME” is displayed, press MODE/
ENTER.
3. Tap the UP button until “LAMP” is displayed, press MODE/
ENTER.
4. Press EXIT to return to the main menu.
CLMP - With this function you can clear the running time of
the lamp. Note Very Important: Please clear the lamp time
every time you replace the lamp.
1. Access the main menu.
2. Tap the UP button until “TIME” is displayed, press MODE/
ENTER.
3. Tap the UP button until “CLMP” is displayed, press MODE/
ENTER.
4. Press MODE/ ENTER, the display will show “ON/OFF”.
5. Press the UP button to select “ON” to activate this function,
or “OFF” to deactivate this function.
Содержание
- Accu roller 250 1
- American d 1
- Table of contents 1
- User instructions 1
- Customer support 2
- Introduction 2
- Unpacking 2
- Warning 2
- Caution 3
- Dmx 512 5
- Power supply 5
- Accu roller 250 set up 6
- Be sure to follow figures two and three when making your own cables do not use the ground lug on the xlr connector do not con nect the cable s shield conductor to the ground lug or allow the shield conductor to come in contact with the xlr s outer casing grounding the shield could cause a short circuit and erratic behavior 6
- Common 6
- Dmx dmx common 6
- Dmx512 6
- Dmx512 in 3 pin xlr 6
- Dmx512 out 6
- Figure 4 6
- If you are making your own cables be sure to use standard two conductor shielded cable this cable may be purchased at almost all professional sound and lighting stores your cables should be made with a male and female xlr connector on either end of the cable also remember that dmx cable must be daisy chained and cannot be split 6
- Notice 6
- Pin xlr 6
- Pin xlr dmx connectors 6
- Special note line termination 6
- Termination reduces signal errors and avoids signal transmission problems and interference it is always advisable to connect a dmx terminal resistance 120 ohm 1 4 w between pin 2 dmx and pin 3 dmx of the last fixture 6
- Xlr pin configuration 6
- Accu roller 250 system menu 7
- Address menu 7
- All resets all the motors in the unit 7
- Alon alone runs the unit stand alone sound active mode 7
- Aoo1 a511 value this is where you set the dmx address of the unit 7
- Audi menu 7
- Clmp clears the lamp running time 7
- Colr color resets the color motors 7
- Gobo resets the gobo motors 7
- Lamp displays the lamp running time 7
- Life displays the fixtures total running time 7
- Mast master runs the unit as master in sound active mode 7
- Rese reset menu 7
- Rpan reverse pan menu on off when on is chosen it will reverse the pan 7
- Rtilt reverse tilt menu on off when on is chosen it will reverse the tilt 7
- Scan resets the motors that control pan tilt 7
- Shtr resets the shutter motors 7
- T 01 t xx test tests the functions of each channel there are eight channels but only channels 1 2 3 4 and 6 can be tested 7
- Test menu 7
- Time menu 7
- Addr main menu 8
- Test main menu 8
- Audi main menu 9
- Rese main menu 9
- Time main menu 10
- Disp main menu 11
- Rpan main menu 11
- Rtilt main menu 11
- Spec main menu 12
- Access the main menu 15
- Adjust the step time needed by pressing the up button 15
- Call up the second scene in your controller now 15
- Change the scene number by pressing the up button 15
- Editing procedure 2 using an external controller 15
- Operating modes the accu scan 250 can operate in three different modes this next section will detail the differences in the operating modes 15
- Press exit to exit the number of steps can be defined under step and the scenes can be called up under run 15
- Press mode enter the display will show c 01 the 1 stands for the channel number 1 15
- Press the up button until cedt is displayed press mode enter 15
- Repeat steps 3 6 until all desired scenes are downloaded 15
- Stand alone operation sound active 15
- Tap the up button until edit is displayed press mode enter 15
- The display shows sc02 you have successfully down loaded the first scene 15
- The display will show off press the up button so that on is displayed press mode enter 15
- The display will show sc01 this stands for the first scene number to be edited for example if sc01 is displayed you will be editing scene 1 15
- Universal dmx control 15
- Audi is displayed and press mode enter 16
- Caution 16
- Lamp replacement 16
- Master slave operation sound active 16
- Warning 16
- 13 spot 14 27 rotating gobo 1 metal 28 41 rotating gobo 2 metal 42 55 rotating gobo 3 dichoric 56 69 rotating gobo 4 metal 70 83 rotating gobo 5 metal 84 97 rotating gobo 6 metal 98 115 rotating gobo 7 metal 116 135 rotating gobo 1 shake 17
- 199 color 0 19 white 20 39 red 40 59 blue 60 79 green 80 99 yellow 100 119 magenta 120 139 orange 140 159 purple 160 179 pink 180 199 light blue 200 255 rainbow effect 4 gobo 17
- 255 pan 17
- 7 no rotation 8 127 forward barral rotation fast slow 128 135 no rotation 136 255 backwards barral rotation slow fast 17
- Barral control 17
- Channel value function 17
- Fixture cleaning 19
- Remove the fixation ring with a small flat head screwdriver or pair of needle nose pliers push the gobo out towards the front when doing this you do not need a lot of pressure 5 change the gobo replace the fixation ring and reassemble the unit 19
- This unit comes with interchangable gobos changing the gobos is a easy procedure follow the instructions below caution never open the unit when in use always disconnect the main power before attempting to change the gobos 19
- To change the gobo you must remove the top half of the units body the top half of the body has the led display on it 19
- Unscrew the four phillips screws on the front of the body remove the top half shell of the body 19
- When you remove the top shell you will be able to access the gobo wheel turn the wheel with your hand until you come across the gobo you would like to change 19
- American d 20
- American dj world headquarters 4295 charter street los angeles ca 90058 usa tel 323 582 2650 fax 323 582 2610 web www americandj com e mail info americandj com 20
- Model accu roller 250 20
- Please note 20
- Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice 20
