Accu Roller 250™ System Menu
American DJ® - www.americandj.com - Accu Roller 250™ Instruction Manual Page 14American DJ® - www.americandj.com - Accu Roller 250™ Instruction Manual Page 13
Accu Roller 250™ System Menu
ADDRESS MENU -
AOO1 - A511 (Value) - This is where you set the DMX address of
the unit.
TEST MENU -
T-01 - T-XX (Test) - Tests the functions of each channel. There
are eight channels, but only channels 1,2,3,4, and 6 can be
tested.
AUDI MENU -
MAST (Master) - Runs the unit as master in sound active mode.
ALON (Alone) - Runs the unit stand alone, sound active mode.
RESE (RESET) MENU -
ALL - Resets all the motors in the unit.
SCAN - Resets the motors that control pan/tilt.
COLR (Color) - Resets the color motors.
GOBO - Resets the gobo motors.
SHTR - Resets the shutter motors.
TIME MENU -
LIFE - Displays the fixtures total running time.
LAMP - Displays the lamp running time.
CLMP - Clears the lamp running time.
RPAN (RE
VERSE PAN) MENU -
ON/OFF - When “On” is chosen it will reverse the pan.
RTILT (REVE
RSE TILT) MENU -
ON/OFF - When “On” is chosen it will reverse the tilt.
ADDR A001~A511 Indicate the staring DMX address
A001 also is the setting for slave
TEST T-01~T-XX Automatically test the function
AUDI MSTR Runs fixture as “master” for audio
ALON Runs fixture as “alone” for audio
RESE ALL ON/OFF Reset all motors and returns fixture to home
SCAN ON/OFF Reset only motors for pan/tilt
COLR ON/OFF Reset only motors for colors
GOBO ON/OFF Reset only motors for gobo and rotation
SHTR ON/OFF Reset only motors for shutter and/or dimmer
TIME LIFE 0000~9999 Displays the total fixture running time
LAMP 0000~9999 Displays a lamps running time
CLMP ON/OFF Clear lamp running time
RPAN ON/OFF Reverses the pan movements
RTLT ON/OFF Reverses the tilt movements
DISP VALU D–XX D-00 (DXXX) Display the DMX512 value of each channel
D ON ON/OFF Display on/off
FLIP ON/OFF This function will reverse the display 180
SPEC SPOT ON/OFF Lamp optimization
DFSE ON/OFF Resets all the fixture functions to default
VER V1.0~V9.9 Software version
EDIT RUN ON/OFF Run your desired program
STEP S–01 ~ S–48 Set the amount of steps in your program
SCXX SC01 - SC30 Scenes that can be edited in your program
C–01 - C-08 01-08 XX(00~FFH) Fixture DMX channel
TIME T – XX(01~FFH) Time of each scene
CEDT ON/OFF Controller Editing
