Accu Roller 250™ System Menu
On-Board System Menu.
The Accu Roller 250™ comes with an
easy to navigate system menu. This next section will detail the func-
tions of each command in the system menu.
Enter Button -
To access the main menu locate the MODE/ENTER
button (4) on the front of the unit. Press this button to activate the
system menu. Tap the UP button (13) until you reach function you wish
to change. When you reach the function you wish to change tap the
MODE/ENTER button. When a function is selected the menu will begin
to flash, use the UP button to change the function. Once your changes
are made tap the MODE/ENTER button again to lock the change in the
system. To exit without making any changes tap the EXIT button (14).
Accu Roller 250™ System Menu
American DJ® - www.americandj.com - Accu Roller 250™ Instruction Manual Page 16American DJ® - www.americandj.com - Accu Roller 250™ Instruction Manual Page 15
DISPLAY MENU -
VALU (DMX-512 Value) - Display the DMX-512 value of each
channel.
D ON (Display On) - Turns digital display on and off.
FLIP - “Flips” the digital display 180º.
SPEC MENU -
SPOT - This provides a spot beam for better lamp optimization.
REST (Reset) - Resets the unit to default.
VER (Version) - Software version 2.2
EDIT MENU -
RUN - This will run your own custom program.
STEP (S-01 - S-48) - These are the steps slots that you write
your programs into. There are at total of 48 steps. See edit pro-
gram, page 27.
SCXX (SC01 - SC30) - These are the scenes that are stored in
your program. There are a total of 30 scenes.
C-01 - C-08 (Channel 1 - Channel 08) - The channels of each
scene that can be edited. See page 27.
TIME (Time) - Running time of the entire program. See page 27.
CEDT - Edit program using a external controller. See page 29.
ADDR MAIN MENU -
ADDR DMX Address Setting via control board -
1. Access the main menu.
2. Tap the UP button until “ADDR” is displayed, press ENTER.
4. Now the display will show “A001”. Adjust the DMX address
by pressing the UP or DOWN buttons.
5. Press MODE/ENTER to confirm.
6. Press the EXIT button to return to the main menu.
When the display is on “A001”, you can directly press the UP
or DN buttons to change the DMX start address.
TEST MAIN MENU -
TEST - This will test the functions of each channel.
1. Access the main menu.
2. Tap the UP button until “TEST” is displayed, press ENTER.
3. The display will show “T-01”. You can now press the up
button and test the different channels. For example: If you
