American DJ® - www.americandj.com - Accu Roller 250™ Instruction Manual Page 24American DJ® - www.americandj.com - Accu Roller 250™ Instruction Manual Page 23
Accu Roller 250™ System Menu Accu Roller 250™ System Menu
6. Press MODE/ENTER to confirm.
7. Press EXIT to return to the main menu.
FLIP - This function will reverse the display 180º.
1. Access the main menu.
2. Tap the UP button until “DISP” is displayed.
3. Press MODE/ENTER, the display will show “ON/OFF”.
4. Press the UP button to select “ON” to activate this function,
or “OFF” to deactivate this function.
5. Press MODE/ENTER to confirm.
6. Press EXIT to return to the main menu.
SPEC MAIN MENU -
spot - With this function you can adjust the lamp via
the control board. The shutter opens and the lamp can be
adjusted. In this mode, the device will not react to any con-
trol signal.
1. Access the main menu.
2. Tap the UP button until “ADJU” is displayed, press ENTER.
3. Tap the UP button until “LADJ” is displayed, press ENTER.
4. The display will show “ON/OFF”.
5. Press the UP button to select “ON” to activate this function,
or “OFF” to deactivate this function.
6. Press ENTER to confirm.
7. Press EXIT/DN to return to the main menu.
DFSE - With this function you can restore the factory
settings of the device. All settings will be set back to the
default values. Any edited scenes will be lost. When restor-
ing the factory settings the unit must be set to the address
that the unit was in when you started editing.
1. Access the main menu.
2. Tap the UP button until “SPEC” is displayed, press MODE/
ENTER.
3. Tap the UP button until “DFSE” is displayed, press MODE/
ENTER.
4. The display will show “ON/OFF”.
5. Press the UP button to display “ON” to activate this function,
or “OFF” to deactivate this function.
6. Press MODE/ENTER to confirm.
7. Press EXIT to return to the main menu.
When you exit this function, the unit will begin to reload
data.
VER - Use this function to display the Software version of
the unit.
1. Access the main menu.
2. Tap the UP button until “SPEC” is displayed, press MODE/
ENTER.
3. Tap the UP button until “VER” is displayed, press MODE/
ENTER.
4. The display will show “V-1.0”, the display may also show, “V-
2.0”, “V-9.9” etc.
5. Press ENTER or EXIT/DN to exit.
