American DJ® - www.americandj.com - Accu Roller 250™ Instruction Manual Page 18
Accu Roller 250™ System Menu
American DJ® - www.americandj.com - Accu Roller 250™ Instruction Manual Page 17
Accu Roller 250™ System Menu
press the up button until “T-03” is displayed, the unit will test
the color channel, changing the color one by one and show the
rainbow effect with different speeds. There are eight channels,
but only channels 1,2,3,4, and 6 can be tested.
5. Press MODE/ENTER or EXIT to exit.
AUDI MAIN MENU -
MSTR Define the unit as the master, in master/slave mode-
1. Access the main menu.
2. Tap the UP button until “AUDI” is displayed, press MODE/
ENTER.
3. Tap the UP button until “MSTR” is displayed, press MODE/
ENTER.
4. Press EXIT to return to the main menu.
ALON Define the unit as a slave, in master/slave mode -
1. Access the main menu.
2. Tap the UP button until “NODE” is displayed, press ENTER.
3. Tap the UP button until “ALON” is displayed, press MODE/
ENTER to confirm.
4. Press EXIT to return to the main menu.
RESE MAIN MENU -
ALL - When you activate the reset function, the fixture will
begin the reset motion.
1. Access the main menu.
2. Tap the UP button until “
RESE” is displayed, press MODE/
ENTER.
3. Tap the UP button until “ALL” is displayed, press MODE/
ENTER.
4. The display will show “ON/OFF”. Press the UP button to
select “ON” to reset the color motor. 5. Press MODE/ENTER to
confirm.
6. Press EXIT/DN to return to the main menu.
SCAN - When you activate this reset function, the fixture
will only reset the pan/tilt motor.
1. Access the main menu.
2. Tap the UP button until “RESE” is displayed, press MODE/
ENTER.
3. Tap the UP button until “SCAN” is displayed, press MODE/
ENTER to confirm.
4. The display will show “ON/OFF”. Press the UP button to
select “ON” to reset the pan/tilt motor. Press MODE/ENTER to
confirm.
5. Press EXIT/DN to return to the main menu.
COLR - When you activate this reset function, the fixture
will only reset the color wheel motor.
1. Access the main menu.
2. Tap the UP button until “RESE” is displayed, press MODE/
ENTER.
3. Tap the UP button until “COLR” is displayed, press MODE/
ENTER to confirm.
4. The display will show “ON/OFF”. Press the UP button to
