American DJ® - www.americandj.com - Accu Fog 1000 Instruction Manual Page 22American DJ® - www.americandj.com - Accu Fog 1000 Instruction Manual Page 21
If you want the set the address to 420, set Channel 1s’ value to
“7”, Channel 2s’ value to “8”, and Channel 3s to “164”. (256 +
164 = 420)
MODE - Choose between ve channel mode or seven
channel mode.
1. Access the main menu.
2. Tap the UP button until “SPEC” is displayed, press ENTER.
3. Tap the UP button until “MODE” is displayed, press ENTER.
4. By pressing the UP button or Down button chose “5CH” or
“7CH”. When the unit is switched to seven channels the unit will
reset.
5. Press ENTER to conrm your selection.
6. Press MODE/ESC to return to the main menu.
DLOF - With this function you can switch the heater on via
the control board.
1. Access the main menu.
2. Tap the UP button until “SPEC” is displayed, press ENTER.
3. Tap the UP button until “SPOT” is displayed, press ENTER.
4. The display will show “ON/OFF”.
5. Press the UP button to select “ON” to activate this function,
or “OFF” to deactivate this function.
6. Press ENTER to conrm.
7. Press MODE/ESC to return to the main menu.
DFSE - With this function you can restore the factory
settings of the device. All settings will be set back to the
Accu Fog 1000 System Menu
default values. Any edited scenes will be lost. When restor-
ing the factory settings the unit must be set to the address
that the unit was in when you started editing.
1. Access the main menu.
2. Tap the UP button until “SPEC” is displayed, press ENTER.
3. Tap the UP button until “DFSE” is displayed, press ENTER.
4. The display will show “ON/OFF”.
5. Press the UP button to display “ON” to activate this function,
or “OFF” to deactivate this function.
6. Press ENTER to conrm.
7. Press MODE/ESC to return to the main menu.
When you exit this function, the unit will begin to reload
data.
FEED - Use this function to activate/deactivate the the
pan/tilt error correction. When the head is bumped or
moved it will return to its previous postion.
1. Access the main menu.
2. Tap the UP button until “SPEC” is displayed, press ENTER.
3. Tap the UP button until “FEED” is displayed, press ENTER.
4. The display will show “ON/OFF”.
5. Press the UP button to select “ON” to activate this function,
or “OFF” to deactivate this function.
6. Press ENTER to conrm.
7. Press MODE/ESC to return to the main menu.
VER - Use this function to display the Software version of
the unit.
Accu Fog 1000 System Menu
