American DJ® - www.americandj.com - Accu Fog 1000 Instruction Manual Page 16
Accu Fog 1000 System Menu
American DJ® - www.americandj.com - Accu Fog 1000 Instruction Manual Page 15
2. Tap the UP button until “PLAY” is displayed, press ENTER.
3. Tap the UP button until “AUTO” is displayed, press ENTER to
conrm.
4. Now you can choose between “AUDI” or “RUN”. “AUDI” is
sound active mode and “RUN” is the auto mode. Select the
mode that you want the xture to run in and press ENTER.
5. Press MODE/ESC to return to the main menu.
HEAT MAIN MENU -
HEAT - With this function you can manually switch the
heater “On” and “Off”.
1. Access the main menu.
2. Tap the UP button until “HEAT” is displayed, press ENTER.
3. Tap the UP button until “HEAT” is displayed, press ENTER.
4. Press MODE/ESC to return to the main menu.
RESE MAIN MENU -
ALL - When you activate the reset function, the xture will
begin the reset motion.
1. Access the main menu.
2. Tap the UP button until “RESE” is displayed, press ENTER.
3. Tap the UP button until “ALL” is displayed.
4. Press ENTER to reset all motors, or press MODE/ESC to
cancel and return to the main menu.
SCAN - When you activate this reset function, the xture
will only reset the pan/tilt motor.
Accu Fog 1000 System Menu
1. Access the main menu.
2. Tap the UP button until “RESE” is displayed, press ENTER.
3. Tap the UP button until “SCAN” is displayed.
4. Press ENTER to reset the pan/tilt motors, or press MODE/
ESC to cancel and return to the main menu.
TIME MAIN MENU -
LIFE - With this function you can display the total running
time of the unit.
1. Access the main menu.
2. Tap the UP button until “TIME” is displayed, press ENTER.
3. Tap the UP button until “LIFE” is displayed, press ENTER.
4. Press MODE/ESC to return to the main menu.
HEAT - With this function you can display the running time
of the heater.
1. Access the main menu.
2. Tap the UP button until “TIME” is displayed, press ENTER.
3. Tap the UP button until “HEAT” is displayed, press ENTER.
4. Press MODE/ESC to return to the main menu.
CLMP - With this function you can clear the running time of
the heater.
1. Access the main menu.
2. Tap the UP button until “TIME” is displayed, press ENTER.
3. Tap the UP button until “CLMP” is displayed, press ENTER.
4. Press ENTER to conrm.
