American DJ® - www.americandj.com - Accu Fog 1000 Instruction Manual Page 9
5-Pin XLR DMX Connectors.
Some manufactures use 5-pin XLR
connectors for DATA transmission in place of 3-pin. 5-pin XLR xtures
may be implemented in a 3-pin XLR DMX line. When inserting stan-
dard 5-pin XLR connectors in to a 3-pin line a cable adaptor must be
used, these adaptors are readily available at most electric stores. The
chart below details a proper cable conversion.
Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)
Pin 1
Pin 5 - Do Not Use
Pin 4 - Do Not Use
Pin 3
Pin 2
Pin 1
Pin 3
Pin 2
Not Used
Not Used
Data True (+ signal)
Data Compliment (- signal)
Ground/Shield
3-Pin XLR to 5-Pin XLR Conversion
Accu Fog 1000 Set Up
American DJ® - www.americandj.com - Accu Fog 1000 Instruction Manual Page 10
Accu Fog 1000 System Menu
0
ADDR
AXXX
A001
Indicate the staring DMX
address
A001 also is the setting for
slave
1
TEST
T-01~T-XX
Automatically test the function
RUN
MSTR/ALON
Runs fixture as “master” or
“alone” for auto
AUDI
MSTR/ALON
Runs fixture as “master” or
“alone” for audio
2
PLAY
AUTO
OFF / RUN /AUDI
Runs fixture for no DMX
3
HEAT
ON/OFF
Manually switches heater “on”
and “off”
ALL
Reset all motors and returns
fixture to home
4
RESE
SCAN
Reset only motors for pan/tilt
LIFE
0000~9999
Displays the total f ixture
running time
HEAT
0000~9999
Displays a heater running time
5
TIME
CLMP
Clear heater running time
6
RPAN
ON/OFF
Reverses the pan movements
7
RTLT
ON/OFF
Reverses the tilt movements
8
MIC
M-XX M-70
Mic sensitivity
VALU
D–XX D-00 (DXXX)
Display the DMX512 value of
each channel
D ON
ON/OFF
Display tur n off after 2mi ns
9
DISP
FLIP
ON/OFF
This function will reverse the
display 180
LAAU
ON/OFF
Automatic heater start with
power
RDMX
ON/OFF
Change DMX address via
external controller
MODE
5CH/7CH/
Channel mode select
DLOF
ON/OFF
Switch he ater via DMX
DFSE
ON/OFF
Resets all the fixture functions
to de fault
FEED
ON/OFF
Pan/tilt feedback (error
correction) on/off
10
SPEC
VER
V1.0~V9.9
Software version
STEP
S–01 ~S–48
Set the amount of your
program
C–01~C–30
0 1
XX(00~FFH)
3 0
XX(00~FFH)
Edit the channels of
each scene
TIME
T
XXX(001~999)
Time for each scene
SCXX
CEDT
ON/OFF
Edit program via
controller
REC.
RE.XX
Auto Save
11
EDIT
RUN
ON/OFF
Program t est
