Accu Fog 1000 System Menu

ADDRESS MENU -

AOO1 - A511 (Value) - This is where you set the DMX address of

the unit.

TEST MENU -

T-01 - T-XX (Test) - Tests the functions of each channel.

PLAY MENU -

RUN - Runs the unit as a “master” in master/slave conguration

ALL - Resets all the motors in the unit.

SCAN - Resets the motors that control pan/tilt.

TIME MENU -

LIFE - Displays the xtures total running time.

HEAT - Displays the heater running time.

CLMP - Clears the heater running time.

RPAN (REVERSE PAN) MENU -

ON/OFF - When “On” is chosen it will reverse the pan.

RTILT (REVERSE TILT) MENU -

ON/OFF - When “On” is chosen it will reverse the tilt.

Accu Fog 1000 System Menu

D ON - Turns digital display off after 2 minutes.

FLIP - “Flips” the digital display 180º.

SPEC MENU -

LAAU - Automatically starts the heater when power is applied.

RDMX - Lets you adjust the DMX address via external controller.

MODE - 5Ch/7Ch With this function you can switch between 5

channels and 7 channels. See page 33 for the 5 Channel DMX

traits, and 34-35 for 7 Channel DMX traits.

DLOF - This lets you switch the heater on via DMX.

DFSE (Default Settings) - Resets the unit to the default settings.

SCXX (SC01 - SC30) - These are the scenes that are stored in

your program. There are a total of 30 scenes.

REC - This will auto save your custom program.

RUN - This will run your custom program.
