ADJ Accu Fog1000 DMX [9/20] Disp main menu

Accu Fog 1000 System Menu

American DJ® - www.americandj.com - Accu Fog 1000 Instruction Manual Page 18American DJ® - www.americandj.com - Accu Fog 1000 Instruction Manual Page 17

5. Press MODE/ESC to return to the main menu.

RPAN MENU -

RPAN - The movement of the Pan will be reversed.

1. Access the main menu.

2. Tap the UP button until “RPAN” is displayed, press ENTER.

4. The display will show “ON/OFF”.

5. Press the UP button to select “ON” to activate this function,

3. Tap the UP button until “RTILT” is displayed, press ENTER.

4. The display will show “ON/OFF”.

5. Press the UP button to select “ON” to activate this function,

or “OFF” to deactivate this function.

6. Press ENTER to conrm.

7. Press MODE/ESC to return to the main menu.

MIC MENU -

MIC - The internal microphone can be made more or less

sensitive.

1. Access the main menu.

Accu Fog 1000 System Menu

7. Press MODE/ESC to return to the main menu.

DISP MAIN MENU -

VALU Display the DMX-512 value of each channel -

1. Access the main menu.

2. Tap the UP button until “DISP” is displayed, press ENTER.

3. Tap the UP button until “VALU” is displayed, press ENTER.

4. “VALU” should now be displayed, press MODE/ESC.

5. The display should show “D-00”. Press the UP button in

order to select the desired channel. If you select “D-05” the

display will only show the DMX value of the 5th channel

2. Tap the UP button until “NODE” is displayed, press ENTER.

3. Tap the UP button until “DISP” is displayed, press ENTER.

4. Tap the UP button until “D-ON” is displayed, press ENTER.
