Accu Fog 1000 System Menu
©American DJ® - www.americandj.com - Accu Fog 1000 Instruction Manual Page 20American DJ® - www.americandj.com - Accu Fog 1000 Instruction Manual Page 19
5. The display will show “ON/OFF”. Press the UP button to
select “ON” to activate this function, or “OFF” to deactivate this
function.
6. Press ENTER to conrm.
7. Press MODE/ESC to return to the main menu.
FLIP - This function will reverse the display 180º.
1. Access the main menu.
2. Tap the UP button until “DISP” is displayed.
3. Press ENTER, the display will show “ON/OFF”.
4. Press the UP button to select “ON” to activate this function,
or “OFF” to deactivate this function.
5. Press ENTER to conrm.
6. Press MODE/ESC to return to the main menu.
SPEC MAIN MENU -
LAAU With this function the heater will start when power
is applied. By default the unit will automatically ingnite
when power is applied. Use this function to disable that
feature.
1. Access the main menu.
2. Tap the UP button until “SPEC” is displayed, press ENTER.
3. Tap the UP button until “LAAU” is displayed, press ENTER.
4. The display will show “ON/OFF”. Press the UP button to
select “ON” to switch on the lamp, or “OFF” to switch off the
lamp.
5. Press ENTER to conrm.
6. Press MODE/ESC to return to the main menu.
RDMX With this function you are able to change the DMX
address via any DMX controller. This function is factory set
to “ON” already.
1. Access the main menu by pressing MODE/ESC.
2. Tap the UP button until “SPEC” is displayed, press ENTER.
3. Tap the UP button until “RDNX” is displayed, press ENTER.
4. The display will show “ON/OFF”. Press the UP button to
select “ON” to activate this function, or “OFF” to deactivate.
5. Press ENTER to conrm, and “PASS” will ash quickly.
6. Press MODE/ESC to return to the main menu.
To use this function follow the instructions:
To adjust the address of your unit you must rst go to the
address that it is currently set to. From there you can adjust the
address. First make sure all channels are set to the value of “0”.
1. On your DMX controller set the DMX value of Channel 1 to
the value “7”.
2. Now set the DMX value of Channel 2 to the value “7” to
adjust the starting address between 1 and 255. To adjust the
address between 256 and 511 set Channel 2 to the value “8” .
3. Set the DMX value of Channel 3 to your desired start-
ing address. This will take about 20 seconds before the unit
accepts the new DMX address.
EXAMPLE: So, if you want the address to be 57, you must rst
set the address that is currently assingned to the unit. The pro-
ceed to set Channel 1s’ value to “7”, Channel 2s’ value to “7”,
and Channel 3s’ value to “57”.
2ND EXAMPLE: Again, if you want the address to be 420, you
must rst set the address that is currently assingned to the unit.
Accu Fog 1000 System Menu
