Connections
PowerJack
1.
1.
2.
2.
3.
4.
Headphones
Jack1
Headphones
Jack2
PowerSupply
UsingHeadphones
Ensurethepianois
turnedoffwhenconnecting
anddisconnectiongthepower.
Therearetwoheadphonejacksontheleftunderneath
thepianobody.
Whenanoptionalsetofstereoheadphonesisconnected
withtheheadphonesjack2,thesoundfromspeakers
willswitchoffautomaticallyresultinginonlysoundfrom
headphonetobeheard.
Whenjack1isconnectedwithstereoheadphones,the
soundcanbeheardfrombothheadphonesandspeakers
ofthepiano.
Turnthevolumeswitch
anti-clockwisetoreach
theminimumvolume
level.
Plugthepowercableinto
anACpoweroutlet.
NOTE:
Whenthepianoisnotinuseorduringathunderstorm,
disconnectthepowerforsafetysake.
Ifyouhavedonetheabove
procedures,youarenow
safetoturnonthepiano.
NOTE:
Neveruseheadphoneswithhighvolume,asitmay
damageyoursenseofhearing.
Topreventdamagingthespeakers,ensurethatthe
volumeissettotheminimumlevelbeforeconnecting
thepowerandotherdevices.
Connecttherear-panelAUX.OUTjacktoamplified
speakers,amplifiersordomestichi-fi-unitsfor
externalamplification.
NOTE:
Connectbothleft(L)andright(R)channelsforthestereo
result.
Ifyouonlyconnecteitheroneofthechannels,the
connectedchannelwillonlytakeeffect.
UsingtheAUX.OUTJack
POWERON/OFFswitch
AUX.OUT
PEDAL
USB
12
