Medeli DP680(PVC) [6/63] Set up guide
![Medeli DP680(PVC) [6/63] Set up guide](/views2/1991921/page6/bg6.png)
1
2
3
4
5
10
9
11
7
8
6
12
Set-upGuide
Beforeproceedingtoassemblethestand,getaPhilipsscrewdriver(notsupplied).
Makesureyouhavethefollowingparts,whicharesuppliedintopackage.
1.Pianocabinet
2.Rightleg
3.Leftleg
4.Rearpanel
5.Pedalbox
6.Handscrew(4pcs)
7.Screw6x24(4pcs)
8.Screw4x15(5pcs)
9.Adhesivechamp(2pcs)
10.Powercable
11.Screw6x12(2pcs)
12.Pedalcable
Φ
Φ
Φ
6
