Memory
Bank
28
Memoryfeaturecanbeusedtopreset48complete
control-panelsetupswhichcouldberecalled
wheneverneeded.
Thereare8banksintotal;eachbankhas6memories
(M1~M6).
Pressbutton,theLCDdisplays"00xMemBank",
with00xshowingtheBankthathasbeenselected.
Use/buttonortoselectthebank.
[BANK]
[+/YES][-/NO]DIAL
Ifthecurrentmemorydatabechanged,thecorrespondingmemory
flagonLCDwillbeerased.
MemoryData
1
2
Thedatacanbestoredtothememoryareasfollows:
VoiceR1,VoiceR2,VoiceL,Style,Tempo,Function,
Mixer,AccompVolumeandOctave.
StoreandLoad
Pressandholdthebutton,thenpressthe
button(or),thecurrentdatawillbestoredin
them.
Pressthebutton(or)toloadthedata
fromthemandreplacethecurrentparameters.
[STORE][M1]
[M2]~[M6]
[M1][M2~[M6]
1
2
Pressandtogetherwhilepowerthepiano,the
memorydatawillbesetasthedefaultvalue.
[STORE][M1]
PressandHold
