Fade
StyleControl
FADEIN:
[FADE]
[FADE]
FADEOUT:
[FADE]
[FADE]
[FADE]
Pressthebuttonwhenstyleisnotplaying,FADE
LEDlights.
FADELEDglimmersafterstylebeginstoplay,stylevolume
willincreasefrom0tomaximabetween10seconds,styleis
playednormallysubsequently,'FADE'LEDdarkens.
PressthebuttonagainwhileFADEOUTstate,
FADELEDglimmers,stylevolumewillbeincreased
tomaximaonthebasisofpresentvolume,styleisplayed
normallysubsequently,'FADE'LEDdarkens.
Pressthebuttonwhenstyleisplaying,FADELED
glimmers,stylevolumewilldecreasefrommaximato0
between10seconds,stylestops.
PressbuttonwhileFADEINstate,willenterFADE
OUTstate,volumeisdecreaseto0onthebasisofpresent
volume,stylestop,'FADE'lampgoesout.
PressbuttonwhileFADEOUTstate,willenterFADE
INstate,volumeincreasetomaximaonthebasisofpresent
volume,styleisplaynormallysubsequently,FADElamp
goesout.
KeepFADEINstatenotchangingasFADEINstatestops
STYLE.
""
""
""
""
""
