SDFunction
Thefilenameincludes1-8characterswhichcanbeinputtedwiththekeyboard.
Keyboard&ASCIICharacterRelativeTableisasfollows:
[DELETE]:
Toerasethecharacterwhich
cursorflashes.
[BACK]:
movethecurrentcursortotheleft.
[NEXT]:
movethecurrentcursortotheright.
[SHIFT]:
26letterswillbedisplayedwith
capitalletterbypressingthekey-
boardinletterareadirectly.
Explanation:
WhileintheSDmode,pressthekeyholdon,itwon't
respondtoit.
Ifthenameinputhasalreadyexisted,LCDwilldisplaySameName
temporarily,thenexittheSDmodetoreturnthepreviousstate.
Ifthere'snoenoughspaceinthecardafternameinput,LCDwill
displayCardFulltemporarily,thenexittheSDmodetoreturnthe
previousstate.
[SHIFT]
""
""
47
PDF created with pdfFactory Pro trial version www.pdffactory.com
