7.Screw6X24(4pcs)Φ
NOTE:
Pleaseuseonlythespecifiedscrewsthataresuppliedwiththepiano.
8.Screw4X15(5pcs)
Φ
11.Screw6ΦX12(2pcs)
Set-upGuide
Fixandwelltightentheleftlegandrightlegtothepedalboxwithscrews.
Fixtherearpaneltothepedalboxwith5screwsandtothelegswith2screws.
A
B
7
