Set-upGuide
Placethepianocabinetonthestand,fixitusing4screws.
Attach2adhesiveclampsonthestandandcabinet.
InserttheDINplugofpedalscableintothepropersocketofcabinet.
Fixthecablewiththeadhesiveclamp.
adhesiveclamp
6.Handscrews(4pcs)
C
D
Placethepianoinitsfinallocationandadjustonfloorthepedalclogunderpedalsgroup.
