ENGLISH 25
Camarillo
Camarillo, 7-string
Controls:
-Volume (Push/Pull):
Volume control pushed = humbucker mode,
volume control pulled = singlecoil mode
(both humbuckers are split)
-Tone
Pickup selector:
3-way
Selector position
1 Neck pickup
2 Neck- and bridge pickup (no hum-canceling in singlecoil mode)
3 Bridge pickup
Renegade Pro
Renegade Custom
Controls:
-Volume (Push/Pull):
Volume control pushed = humbucker mode,
volume control pulled = singlecoil mode
(both humbuckers are split)
-Tone
Pickup selector:
3-way
Selector position
1 Neck pickup
2 Neck- and bridge pickup (no hum-canceling in singlecoil mode)
3 Bridge pickup
