ENGLISH 26
Tennessee Pro
Tennessee Custom
Controls:
-Volume
-Tone
Pickup selector:
3-way
Selector position
1 Neck pickup
2 Neck- and bridge pickup
3 Bridge pickup
Panthera Pro
Panthera Custom
Panthera Custom, 7-string
Controls:
-Volume
-Tone
Pickup selector:
3-way
Selector position
1 Neck pickup
2 Neck- and bridge pickup
3 Bridge pickup
