ENGLISH 28
Streetwalker, 6-string
Controls:
Volume with push/pull function:
Volume control pushed = humbucker activated and neck
singlecoil bypassed, volume control pulled = humbuckers are
bypassed and neck singlecoil is activated (regardless of
selector position)
Pickup selector:
3-way
Selector position
1 Neck humbucker
2 Neck- and bridge humbucker
3 Bridge humbucker
Streetwalker, 7-string
Controls:
Volume
Pickup selector:
3-way
Selector position
1 Neck pickup
2 Neck- and bridge pickup
3 Bridge pickup
