![FRAMUS 1786865115CPMAHO2F [42/44] English 42](/views2/1991927/page42/bg2a.png)
ENGLISH 42
English Description
Body Basic guitar component
Binding Ornamental border around the body, neck or headstock made of plastic, wood (with lacquer treatment) or
mother-of-pearl
Bookmatched Wood block is cut open in half and glued like a mirror image
Bottom, back Bottom part of a multi-piece body
Top Top part of a multi-piece body
Side Curved sides between top and bottom in hollow-body guitars
Veneer Thin layer of wood glued on top or in-between
TCS Tone Chamber System, specific wood carving to influence ringing properties
Neck Basic guitar component, strings run over it
Bolt-on neck Neck joint that uses four screws from the back
Bolt-in neck Neck joint that uses two screws from the front and two from the back
Fingerboard Wood with frets that is glued onto the neck
Fingerboard inlay Inlays made of mother-of-pearl or other material that mark fretting positions
Frets
Thin metal bars on the fingerboard. Pressing the string on the fret will shorten its length and produce a
pitched sound
Headstock End part or the neck with tuning machines
Matched headstock Headstock with the same surface as the body
Nut String rest at the headstock
Hardware All metal components of the guitar
Bridge String rest at the body
Tailpiece String fixation behind the bridge
Saddle Individual adjustable string rest at the bridge
String spacing Gap between each string usually measured at the bridge
Scale Length of a free-oscillating string
Intonation String length adjustment to ensure the correct pitch at every position on the fingerboard
Vibrato Bridge system that allows pitch modulations through controlled alteration of the string tension
Tremolo A wavering effect on a note, either by rapid repetition of one or two pitches, also used as a synonym for vi-
brato bridge
Attack Beginning of string oscillation
Sustain Duration of string oscillation
Machine head Used for the tuning of the string
Tuning key Turning part of the machine heads
Truss rod Used for adjusting the neck’s relief (neck bow)
Truss rod cover Cover for the truss rod’s access
Pickguard Plate made of wood, plastic or celluloid mounted on the body to prevent the scratching of the surface that
comes from hitting the strings
Pickup Mostly magnetic converters that transforms the string’s mechanical oscillations into electrical oscillations
Singlecoil A pickup that consists of only one coil
Humbucker Hum-canceling pickup with two coils
Hum-canceling Also called humbucking. It happens when two pickup coils with opposite polarity are connected together
either in series or parallel thus canceling the typical 50- to 60- cycle hum that is characteristic of a singlecoil
Trembucker Humbucker with wider string spacing
Potentiometer Electrical component to regulate volume or tone of a sound source
Push / pull pot Potentiometer with a switch that is activated by pulling up or pushing down
Pickup selector switch Allows for switching between the different pickup configurations
Security lock Locking strap fixation
Finish Surface treatment
Natural Oil Finish Oiled wood surface
Colored Oil Finish Stained clear-lacquered matte surface
Stain High Polish Stained high-polished clear-lacquered surface
High Polish Colored high-polished surface
