ENGLISH 29
AK 1974
Controls:
-Volume
-Tone
Pickup selector:
-6-way rotary switch
Rotary switch position
1 Neck- and bridge pickup
2 Neck pickup
3 Both humbuckers are split, inner coils are active
4 Bridge pickup
5 Both humbucker are split, neck outer coil and bridge inner coil are active
6 Neck- and bridge pickups are out of phase
AZ-10 Single Pickup
AZ-10 Blonde
AZ-10 Bubinga
AZ-10 Makassar
AZ-10 Koa
AZ-10 Shellac
Controls:
-Volume
-Tone
