English | 312 610 A15 112 12.8.09
Remote control
Safety Notes
Read and observe all instructions.
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
f Have the remote control repaired only
through a qualified repair person and only
using identical replacement parts. This will
ensure that the functionality of the remote control
is maintained.
f Do not operate the remote control in explo-
sive atmospheres, such as in the presence of
flammable liquids, gases or dusts.
Sparks can be created in the remote control which
may ignite the dust or fumes.
f Read and strictly observe the safety warn-
ings in the operating instructions of the rota-
tional laser.
Functional Description
Intended Use
The remote control is intended for controlling the rota-
tional laser ALGR indoors and outdoors.
Product Features
The numbering of the product features refers to the
illustration of the remote control on the graphics page.
26 Outlet opening for infra-red beam
27 Remote control operation indicator
28 Button for programmable line
29 Button for grade upward and increase of the rota-
tional speed
30 Button for decreasing the aperture angle
31 Direction and grade button (rightwards) on the
remote control
32 Button on the remote control for clockwise rota-
tion of the rotation head
33 Battery lid latch of the remote control
(on the rear side)
34 Battery lid of the remote control
(on the rear side)
35 Serial number
36 Button for grade downward and decrease of the
rotational speed
37 Button on the remote control for anticlockwise
rotation of the rotation head
38 Function-mode button on the remote control
39 Direction and grade button (leftwards) on the
remote control
40 Button for increasing the aperture angle
Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
Technical Data
Assembly
Inserting/Replacing the Battery
Using alkali-manganese batteries is recommended for
operation of the remote control.
The remote control is provided with batteries inserted.
Before putting into operation for the first time, remove
the safety strip in the battery compartment (“Remove
before Use”).
The batteries must be replaced when operation indi-
cator 27 no longer lights up after pressing any button
on the remote control.
To open the battery lid 34, press on the latch 33 and
remove the battery lid. Insert the batteries. When
inserting, pay attention to the correct polarity accord-
ing to the representation on the inside of the battery
compartment.
Always replace all batteries at the same time. Only
use batteries from one brand and with the identical
capacity.
f Remove the batteries from the remote con-
trol when not using it for longer periods.
When storing for longer periods, the batteries can
corrode and discharge themselves.
Remote control RC400X
Article number F 034 K69 AN7
Working range
1)
30 m
Batteries 2 x 1.5 V LR06 (AA)
Weight according to
EPTA-Procedure 01/2003 115 g
1) The working range can be decreased by unfavourable envi-
ronmental conditions (e.g. direct sun irradiation).
Please observe the article number on the type plate of your
remote control. The trade names of individual remote controls
may vary.
For clear identification of your remote control, see the serial
number 35 on the type plate.
